Available models of Tubular Stranding Machine
| Model | JGG500/6 | JGG630/6 | JGG630/12 | JGG500/12+1000/1 | JGG630/12+1250/1 | JGG630/18+1400/1 |
| Individual wire diameter (mm) | Cu,Steel1.3~3.5, Al 1.7~4.6 | Cu 2~5, Al 2.5~5, Steel 1.8~4.5 | Cu 2~5, Al 2.5~5, Steel 1.8~4.5 | Cu, Steel 1.3~3.5, Al.7~4.6 | Cu 2~5, Al 2.5~5, Steel 1.8~4.5 | Cu 2~5, Al 2.5~5, Steel 1.8~4.5 |
| Stranding diameter (mm) | 15 | 15 | 15 | 23 | 25 | 35 |
| Main machine rotating speed (RPM) | 650 | 600 | 450 | 300 | 240 | 200 |
| Delivery speed (m/min) | 90 | 90 | 70 | 60 | 60 | 60 |
